Mitutoyo 209-350 Dial Caliper Gauges Internal Type Series 209

Mitutoyo 209-350 Dial Caliper Gages Internal Type Series 209

Features:

These Dial Caliper Gages are used only as comparison gages, and should be used along with a Setting Ring or micrometer.The caliper is spring loaded and makes point contact measuring pressure.

• Range: .10-.50 inch
• Graduation: .0002 inch
• Accuracy: .0008 inch
• Max Meas Depth L: .47 inch
• Max Groove Depth A: .027 inch
• Min. Groove Width B: .023 inch
• Measuring Contacts: A
• Size: RO .1mm
• Weight: 200g
