Mitutoyo Caliper Jaw Micrometer, 0-1" - 143-121
  • Mitutoyo Caliper Jaw Micrometer, 0-1" - 143-121
  • Mitutoyo Caliper Jaw Micrometer, 0-1" - 143-121
Mitutoyo Caliper Jaw Micrometer, 0-1" - 143-121

Mitutoyo Caliper Jaw Micrometer, 0-1" - 143-121

$445.54
$445.54

Series 143

  • With Ratchet Stop for constant force
  • With a standard bar except 0 - 25mm and 0 - 1" model
  • Supplied in fitted plastic case


Technical Data:

Accuracy Refer to below list of specifications
Resolution* 0.001mm or .00005"/0.001mm
Graduation** 0.01mm / .001"
Flatness 0.3ìm / .000012”
Parallelism (3+R/75)ìm, R=max. range (mm)
merge up [.00012” + .00004” (L/8)]”
merge up L = Max, range (inch)
Measuring faces Carbide tipped, micro-lap finish
Measuring spindle ø 6,35 mm, spindle pitch 0,5 mm
Display* LCD
Battery* SR44 (1 pc.), 938882
Battery life* Approx. 1.2 years under normal use
